Product Overview

Set of 4 DRD aluminium injector cap / sleeve / insert replacements for VW & Audi 1.8T 20V engines.

These are 27mm large type (M27 x 1.5 thread) inserts with a 14mm internal diameter for injector O-ring sealing.

Designed for use on most 20V small port intake manifolds and compatible with both standard fuel rails and aftermarket/direct replacement fuel rails.

Available in two injector length versions to suit different injector setups.

⚙ Specifications

Thread: M27 x 1.5
Outside Diameter: 27mm (Large Type)
Internal Diameter: 14mm (O-ring seat)
Material: High-quality aluminium
Quantity: Set of 4

✔ Engine Compatibility

Designed to work on VW & Audi 1.8T 20V engines including (but not limited to):

APH, APU, AQX, ARX, AUM, AVJ, AWD, AWT, AWU, AWV, AWW, AYP, BFB, AMB, AWM, ARY, AUQ, AWP, BEX, AMK, BAM

Typically found on:

Audi A4 B5 / B6 1.8T
Audi TT 1.8T
VW Golf 4 GTI 1.8T
VW Jetta / Bora 1.8T
Seat Leon Cupra 1.8T
Skoda Octavia 1.8T

(Small port 20V intake manifolds and limited large port applications)

✔ Version Options

V2 – Medium Injector Length

48.65mm between O-rings

Commonly used with (but not limited to):
Bosch 550cc – 0280158117
Bosch 380cc – 0280156063

V3 – Short Injector Length

33.6mm between O-rings

Commonly used with (but not limited to):
Bosch 980cc – 0280158040
Bosch 627cc – 0280158123

⚠ Important Installation Notes

Threads in the intake manifold must be cleaned thoroughly.
All carbon build-up and old sealant must be removed.
Failure to clean threads properly may result in manifold cracking or splitting.
PTFE tape or fuel-resistant thread sealant must be applied to prevent air leaks.

To avoid confusion, measure your insert outside diameter before ordering.
It must measure 27mm, not 24mm.

Injector installation tool sold separately.
Injectors not included.
